KEL-FW | Split bulkhead for 90° cable entry
for cables with connectors and a large bending radius / IP65
The new bulkhead KEL-FW is perfect for routing cables with/without connectors at a 90° angle over a large bending radius (max. 150 mm).
The hinged cover of the new bulkhead KEL-FW is firmly connected to the housing by a hinge and is therefore captive. This makes the system very easy and quick to mount. The KEL-FW is first screwed to the enclosure using the two rear holes and then fitted with the required cable grommets. The cover is then folded down, locked in place and screwed to the enclosure using the two front holes.
The KEL-FW is fitted with an integrated seal to achieve the high protection rating of IP65 (when using single hole grommets). An additional flat gasket for wall mounting is included in the shipment.
Cables with and without connectors up to a diameter of 35 mm can be routed and strain-relieved according to EN 62444. Retrofitting and maintenance can be carried out quickly and easily.
Part No.
42461
Specifications
Flame class
UL94-V0, self-extinguishing
Temperaturbereich Range Max
90 C°
Properties
Halogenfrei, Silikonfrei
Temperaturbereich Range Min
-40 C°
Advantages and benefits
Hinged cover
Integrated seal
Cable entry at 90° to the enclosure
Large bending radius of the routed cables possible (r max. = 150 mm)
Mechanical protection of the cable directly at the place of entry
Protection against water splashes and drips
Warranty on pre-terminated cables remains
Retrofittings and maintenance can be done quickly and easily
Ideal for cables with connectors (max. Ø 35 mm)
Strain relief according to EN 62444
High stability, vibration resistant
Can be combined with IMAS-CONNECT adapter grommets
